Measurement Principle: Dual-beam spectrophotometer
Geometry: Tt/0º or Td/0º per ASTM 1164, CIE 15:2018
Spectrophotometer: 256 element diode array and high resolution, concave holographic grating
Port Size/Measured Area: 11 mm (0.43 in) illuminated/9.8 mm (0.39 in) measured
Measurement Time: 2.5 seconds
Measurement Time with Haze: 5 seconds
Measurement Interval: min 3 seconds
Measurement Pathlength: Up to 100 mm
Transmission Modes: Total (TTRAN) and Regular (RTRAN) and Haze
Standards Conformance
Colorimetric: CIE 15:2018, ASTM E1164, DIN 5033 Teil 7 and JIS Z 8722 Condition E, G
Haze: ASTM D1003
